Rich Solar MEGA 430 BIFACIAL | 430W Bifacial N-Type Solar Panel | Premium 24V Grid-tie or Off-grid Solar Panel for Residential, Commercial, Agriculture | 25-Year Output Warranty | UL Certified

Features

Unmatched Performance

• 22.0% Module Efficiency: Industry-leading conversion with +5W positive tolerance
• 430W Maximum Output: High power density reduces BOS (Balance of System) costs
• -0.30%/°C Pmax Coefficient: Superior heat resistance (up to 185℉) for stable desert performance

Breakthrough Cell Technology

• N-TOPCon Cells: 10–30% higher yield than conventional P-type modules
• Zero LID: Minimal 1% first-year degradation for lasting output
• Passivated Contact Design minimizes power degradation

Advanced Bifacial Design

• 80%+ Bifaciality Factor maximizes rear-side energy harvest
• 15–25% Additional Yield in standard ground-mounted systems
• Dual-Glass Construction: 94% light transmittance for maximum albedo utilization

Military-Grade Durability

• 5400Pa Front Load: Certified for heavy snow regions
• 2400Pa Wind Load: Withstands hurricane-force winds
• IP68 Protection: Fully submersible junction box

Versatile Applications

• BIPV (Building-Integrated Photovoltaics)
• Vertical Mounting Systems
• Extreme Environments: Coastal / Desert / Arctic (up to -40℉)

Intelligent Integration

• 1500V System Voltage Ready: Reduces wiring costs
• MC4-Compatible Connectors for plug-and-play installation
• 30A Fuse Rating: Meets global safety standards

Warranty

• 12-year product warranty + 30-year linear power output guarantee (≤0.4% annual degradation)

Specifications

• Model: RS-M430BF
• Peak Power: 430W
• Module Efficiency: 22.0%
• Max Power Voltage (Vmp): 31.9V
• Max Power Current (Imp): 13.5A
• Open Circuit Voltage (Voc): 37.4V
• Short Circuit Current (Isc): 14.7A
• Max Series Fuse Rating: 30A
• Maximum System Voltage: 1500VDC
• Cell Type: Monocrystalline
• Number of Cells: 6 x 18 (108 cells total)
• Front Glass: 2.0 mm Tempered Glass
• Frame Material: Anodized Aluminium Alloy
• Operating Temperature: -40°F to 185°F (-40℃ to +85℃)
• Dimensions: 67.8" L × 44.7" W × 1.2" H (1722 × 1134 × 30 mm)
• Weight: 45.4 lb (20.6 kg)
