- MPPT
- Tracking Efficiency Above 99.5%
- Charge Conversion Efficiency as high as 98%
- 12V/24V DC System Self-Adaptation
- Reverse Discharge Protection
- Targeted for Accuracy
- Overvoltage Protection
- Common Negative Connection
- Charging Data Storage
- Conformal Coating For Inside Board
- In-house Design And Manufacture
- Extensive Internal Electronics, In-Circuit Protections, And Safety Protections
- Targeted For Lead Acid Batteries: Gel, AGM, WET, CRYSTAL, CALCIUM Batteries Type Selections
- Targeted For Lithium Batteries: LiFePO4, LTO (Lithium Titanium Oxide), LCO Batteries Type Selections
Specifications
-
System Nominal Voltage: 12/24V Auto
-
Max. PV Open Circuit Voltage: 100V DC
-
Charging Technology: MPPT
-
Max PV Charging Current: 40A
-
Max. Recommended PV Input Power: 600 Watt (12V) / 1200 Watt (24V)
-
Charge Conversion Efficiency: ≤98%
-
MPPT Tracking Efficiency: >99.5%
-
Battery Type Preset: Crystal, Gel, AGM, WET, Calcium / LCO, LFP, LTO
-
Housing Case Color: Black / Grey
-
IP Grade: IP43 for Inside PCBA, IP22 for Connection Area
-
Net Weight: 1.17kg / 2.58lb
-
Dimensions (L*W*H): 195*142*74 mm / 7.7*5.5*2.9 in
Advanced MPPT Technology
The Rich Solar BRAVO 40 is equipped with cutting-edge 40 Amp MPPT solar charge controller technology. MPPT stands for Maximum Power Point Tracking, which optimizes the energy output from your solar panels. This feature allows the controller to adjust its input to maximize energy capture, especially under varying weather conditions. Therefore, it ensures that you receive the maximum possible power from your solar system, making it an essential component for any RV, trailer, or off-grid application.
Versatile Voltage Compatibility
This solar charge controller operates seamlessly with both 12V and 24V systems. Because of its wide voltage range, users can easily integrate it into various setups, including RVs, campers, and boats. This flexibility means that whether you are setting up a new system or upgrading an existing one, the Rich Solar BRAVO 40 can accommodate your needs. As a result, it becomes an indispensable tool for anyone aiming for renewable energy efficiency.
User-Friendly Interface
Your experience with the Rich Solar BRAVO 40 will be hassle-free thanks to its user-friendly interface. The clear LCD display provides real-time data on your system's performance, allowing you to monitor charging status, battery voltage, and solar input. This intuitive design helps users understand their system easily, making it ideal for both beginners and seasoned solar veterans. Additionally, enhanced safety features protect against overcharging and excessive discharging, ensuring your solar setup remains efficient and reliable.
